iPF760
• Using rolls with a 3-inch paper core
Holder Stopper (Left Side)
Align the tips (a) of the 3-Inch Paper Core Attachment L with the
holes (b) of the Holder Stopper and insert it firmly.
3
With the edge of the roll paper facing forward as shown,
insert the Roll Holder from the right of the roll. Insert it
firmly until the roll touches the flange (a) of the Roll Hold-
er, leaving no gap.
User's Guide
Roll Holder (Right Side)
Align the tips (a) of 3-Inch Paper Core Attachment R with the
holes (b) of the Roll Holder and insert it firmly.
Attaching the Roll Holder to Rolls
441
