Statistics from Classification Groups

The classification groups that you define in a report will determine what type of statistics that can be
derived for that report. This is shown in the following diagrams.
The following figure shows how statistics are calculated per bin when bins are present but groups are not
present. For example, if each bin represents a different date, and the source data is a traffic measurement,
then the statistic here could be the total amount of traffic per day. See
Figure 37
The next figure shows statistics calculated per group when both bins and groups are present. For example,
if each bin represents a different date, the source data is a traffic measurement, and the grouping is done by
username, then the group statistic here is "traffic per user", and the end result is "traffic per user per day".
Figure 38

Components of the Report Editor

To create a new report using the Report Editor (shown above), start at the top left and go clockwise,
following the arrows, until you have a final report.
Amigopod 3.7 | Deployment Guide
Reporting – Bin statistics without groups
Reporting – Bin statistics with groups
Figure 37.
Report Management | 251
