iPF6450

Spectrophotometer Unit Calibration white tile error.

Spectrophotometer Unit Calibration white tile error.
Cause
The White Calibration Tile is
not installed.
The White Calibration Tile is
dirty.
The performance of part of the
Spectrophotometer Sensor
may be impaired.

Spectrophotometer Unit eject guide not mounted.

Spectrophotometer Unit eject guide not mounted.
The Spectrophotometer Eject Guide is installed incorrectly,
such as being installed askew, or not pushed in all the way.
There is a foreign object on the Spectrophotometer Eject
Guide.
The performance of part of the Spectrophotometer Unit may
be impaired.

Spectrophotometer Unit Backing plate error.

Spectrophotometer Unit Backing plate error.
Cause
The White/Black Backing Plate is not instal-
led correctly.
The White/Black Backing Plate is soiled.

Spectrophotometer up-down unit cover open.

Spectrophotometer up-down unit cover open.
The Up-down Unit Cover of the Spectrophotometer Unit is open.

Spectrophotometer Unit cover open.

Spectrophotometer Unit cover open.
The Spectrophotometer Unit Cover of the Spectrophotometer Unit is
open.

Spectrophotometer read error.

Spectrophotometer read error.
Cause
The Spectrophotometer Sensor
to be loaded into the Spectro-
photometer Carriage is not in-
stalled correctly.
The color measurement pattern
was not printed correctly.
The color measurement pattern
is out of alignment.
Basic Guide
Install the White Calibration Tile.
(See "Replacing the Spectrophotometer Sensor of the Spectrophotometer Unit (option).")
→User's Guide
Remove, clean, and reinstall the White Calibration Tile.
(See "Cleaning the Spectrophotometer Unit (option) Parts.")
If this message is still displayed after cleaning the White Calibration Tile, we recommend adjusting the
Spectrophotometer Sensor.
Contact your Canon dealer for more information on adjustment services.
(See "Replacing the Spectrophotometer Sensor of the Spectrophotometer Unit (option).")
→User's Guide
Cause
Remove and correctly attach the White/Black Backing Plate, and then press the OK button.
(See "Switching the White/Black Backing Plate (Optional) Color.")
Clean the White/Black Backing Plate and then press the OK button.
(See "Cleaning the Spectrophotometer Unit (option) Parts.")
Cause
Cause
Turn off the power, and reinstall by pushing the two connectors all the way into the Spectrophotometer
Sensor.
(See "Replacing the Spectrophotometer Sensor of the Spectrophotometer Unit (option).")
→User's Guide
Check the color measurement pattern. If the printing is faint, clean the printhead and perform the opera-
tion again.
(See "Cleaning the Printhead.")
Pulling or lifting a printed color measurement pattern may cause the pattern to come out of alignment.
Perform the operation again taking care not to touch the color measurement pattern.
Execute Feed Priority to improve the printing position of the pattern for color measurement.
Spectrophotometer Unit Calibration white tile error.
Corrective Action
Corrective Action
Make sure that the Spectrophotometer Eject Guide is loaded in the correct
position, push it in all the way, and press the OK button.
Remove the foreign object and press the OK button.
Turn off the printer, wait a while, and then turn it on again.
If the same message is displayed again, contact your Canon dealer for as-
sistance.
Corrective Action
Corrective Action
Close the Up-down Unit Cover and press the OK button.
Close the Spectrophotometer Unit Cover and press the OK button.
Corrective Action
→P.53
→P.54
→User's Guide
→P.54
Corrective Action
147
