Inside The Roll Feed Unit Cover - Canon imagePROGRAF iPF6450 Basic Manual

iPF6450
f Paper Alignment Line
Load heavyweight sheets parallel to this line.

Inside the Roll Feed Unit Cover

Inside the Roll Feed Unit Cover
a Roll Holder
Load the roll on this holder.
b Holder Stopper
Secure rolls on the Roll Holder with this part.
c Roll Holder Slot
Slide the Roll Holder into this slot.
Carriage
Carriage
a Printhead Fixer Cover
Holds the Printhead in place. Do not open this part except during Printhead replacement.
b Printhead
The printhead is equipped with ink nozzles. It serves a key role in printing.
Basic Guide
Inside the Roll Feed Unit Cover
75
