Loading Rolls on the Roll Holder
Follow steps 3 and 4.
1
Remove the Holder Stopper from the Roll Holder.
2
Insert the attachments for the roll paper on the Roll Holder.
• Using rolls with a 3-inch paper core
Attach the included 3-Inch Paper Core Attachment
on the Roll Holder.
Align the triangular part (b) of the 3-Inch Paper
Core Attachment (a) with the triangular part (c) of
the Roll Holder as shown, and insert the 3-Inch Pa-
per Core Attachment into the Roll Holder.
Use the Holder Stopper for 3-inch paper cores.
• Borderless printing on A1 or A2 rolls
Attach the included Spacer for Borderless Printing to the
Roll Holder.
Insert the protrusions (b) of the Spacer for Borderless
Printing (a) into the holes (c) of the Roll Holder, as
shown.
