iPF6450
Back
Back
a USB Port
Connect a USB cable to this port. The printer is compatible with Hi-Speed USB connections.
b LAN connector (Gigabit Ethernet)
Connect a LAN cable to this port.
c Power Supply Connector
Connect the power cord to this connector.
d Carrying Handles (5)
When carrying the printer, hold it by these handles under both sides.
Top Cover (Inside) Top Cover (Inside)
a Carriage
Mounts the Printhead, and moves to the left and right. This is an important part for printing. (See "Carriage.")
→P.75
