Cleaning the Spectrophotometer Unit (option) Parts
6
Grasp the part with the blue label in the central part
of the Spectrophotometer Carriage and move it to
the position shown in the diagram.
7
Move the White Calibration Tile Holder in the direc-
tion of the arrow and remove it from the Up-down
Unit.
Important
8
Push the (a) part of the White Calibration Tile Hold-
er and remove the White Calibration Tile.
56
Do not touch the (a) part of the White Calibration Tile
•
Holder except when removing the White Calibration Tile.
Doing so may cause the White Calibration Tile to fall,
which can lead to damage.
