About This Guide
This manual accompanies the Spartan®-6 FPGA SP605 Evaluation Board and contains
information about the SP605 hardware and software tools.

Guide Contents

This manual contains the following chapters:
•
•
•
•
•

Additional Documentation

The following documents are available for download at
http://www.xilinx.com/products/spartan6/.
•
•
•
•
•
•
SP605 Hardware User Guide
UG526 (v1.1.1) February 1, 2010
Chapter 1, "SP605 Evaluation Board,"
development board and details the components and features of the SP605 board.
Appendix A, "Default Jumper and Switch Settings."
Appendix B, "VITA 57.1 FMC LPC Connector Pinout."
Appendix C, "SP605 Master UCF."
Appendix D, "References."
Spartan-6 Family Overview
This overview outlines the features and product selection of the Spartan-6 family.
Spartan-6 FPGA Data Sheet: DC and Switching Characteristics
This data sheet contains the DC and switching characteristic specifications for the
Spartan-6 family.
Spartan-6 FPGA Packaging and Pinout Specifications
This specification includes the tables for device/package combinations and maximum
I/Os, pin definitions, pinout tables, pinout diagrams, mechanical drawings, and
thermal specifications.
Spartan-6 FPGA Configuration User Guide
This all-encompassing configuration guide includes chapters on configuration
interfaces (serial and parallel), multi-bitstream management, bitstream encryption,
boundary-scan and JTAG configuration, and reconfiguration techniques.
Spartan-6 FPGA SelectIO Resources User Guide
This guide describes the SelectIO™ resources available in all Spartan-6 devices.
Spartan-6 FPGA Clocking Resources User Guide
www.xilinx.com
provides an overview of the embedded
