User SMA GPIO

The SP605 includes an pair of SMA connectors for GPIO as described in
Table
X-Ref Target - Figure 1-19
Table 1-27: User SMA Connections
SP605 Hardware User Guide
UG526 (v1.1.1) February 1, 2010
1-27.
USER_SMA_GPIO_N
USER_SMA_GPIO_P
U1 FPGA Pin Schematic Net Name
A3 USER_SMA_GPIO_N
B3 USER_SMA_GPIO_P
www.xilinx.com
1
J39
1
J40
Figure 1-19: User SMA GPIO
GPIO SMA Pin
J39.1
J40.1
Detailed Description
Figure 1-19
32K10K-400E3
2
GND1
3
GND2
4
GND3
5
SIG GND4
6
GND5
7
GND6
8
GND7
32K10K-400E3
2
GND1
3
GND2
4
GND3
5
SIG GND4
6
GND5
7
GND6
8
GND7
UG526_19 _092409
and
45
