Table 1-20: IIC Memory Connections
References
See the ST Micro M24C08 Data Sheet for more information.
In addition, see the Xilinx XPS IIC Bus Interface Data Sheet.
SP605 Hardware User Guide
UG526 (v1.1.1) February 1, 2010
U1 FPGA Pin Schematic Netname
Not Applicable Tied to GND
Not Applicable Tied to GND
Not Applicable Pulled up (0 ohm) to VCC3V3
R22 IIC_SDA_MAIN
T21 IIC_SCL_MAIN
Not Applicable Tied to GND
www.xilinx.com
Detailed Description
IIC Memory U4
Pin Number Pin Name
1 A0
2 A1
3 A2
5 SDA
6 SCL
7 WP
[Ref 18]
[Ref 8]
