SP605 Master UCF
The UCF template is provided for designs that target the SP605. Net names provided in the
constraints below correlate with net names on the SP605 rev. C schematic. On identifying
the appropriate pins, the net names below should be replaced with net names in the user
RTL. See the
NET "CLK_33MHZ_SYSACE"
NET "CPU_RESET"
##
NET "DVI_D0"
NET "DVI_D1"
NET "DVI_D2"
NET "DVI_D3"
NET "DVI_D4"
NET "DVI_D5"
NET "DVI_D6"
NET "DVI_D7"
NET "DVI_D8"
NET "DVI_D9"
NET "DVI_D10"
NET "DVI_D11"
NET "DVI_DE"
NET "DVI_GPIO1"
NET "DVI_H"
NET "DVI_RESET_B"
NET "DVI_V"
NET "DVI_XCLK_N"
NET "DVI_XCLK_P"
##
NET "FLASH_A0"
NET "FLASH_A1"
NET "FLASH_A2"
NET "FLASH_A3"
NET "FLASH_A4"
NET "FLASH_A5"
NET "FLASH_A6"
NET "FLASH_A7"
NET "FLASH_A8"
NET "FLASH_A9"
NET "FLASH_A10"
NET "FLASH_A11"
NET "FLASH_A12"
NET "FLASH_A13"
NET "FLASH_A14"
NET "FLASH_A15"
NET "FLASH_A16"
NET "FLASH_A17"
NET "FLASH_A18"
NET "FLASH_A19"
NET "FLASH_A20"
NET "FLASH_A21"
NET "FLASH_A22"
NET "FLASH_A23"
NET "FPGA_D0_DIN_MISO_MISO1"
NET "FPGA_D1_MISO2"
NET "FPGA_D2_MISO3"
NET "FLASH_D3"
NET "FLASH_D4"
NET "FLASH_D5"
NET "FLASH_D6"
NET "FLASH_D7"
NET "FLASH_D8"
NET "FLASH_D9"
NET "FLASH_D10"
NET "FLASH_D11"
NET "FLASH_D12"
NET "FLASH_D13"
NET "FLASH_D14"
NET "FLASH_D15"
NET "FLASH_WAIT"
SP605 Hardware User Guide
UG526 (v1.1.1) February 1, 2010
Constraints Guide

for more information.

LOC = "N19"; ## 93 on U17
LOC = "H8"; ## 2 on SW6 pushbutton (active-high)
LOC = "K16"; ## 63 on U31 (thru series R39 47.5 ohm)
LOC = "U19"; ## 62 on U31 (thru series R38 47.5 ohm)
LOC = "T20"; ## 61 on U31 (thru series R37 47.5 ohm)
LOC = "N16"; ## 60 on U31 (thru series R36 47.5 ohm)
LOC = "P16"; ## 59 on U31 (thru series R35 47.5 ohm)
LOC = "M17"; ## 58 on U31 (thru series R34 47.5 ohm)
LOC = "M18"; ## 55 on U31 (thru series R33 47.5 ohm)
LOC = "R15"; ## 54 on U31 (thru series R32 47.5 ohm)
LOC = "R16"; ## 53 on U31 (thru series R31 47.5 ohm)
LOC = "P17"; ## 52 on U31 (thru series R30 47.5 ohm)
LOC = "P18"; ## 51 on U31 (thru series R29 47.5 ohm)
LOC = "R17"; ## 50 on U31 (thru series R28 47.5 ohm)
LOC = "J17"; ## 2 on U31 (thru series R40 47.5 ohm)
LOC = "D22"; ## 18 on U31
LOC = "J16"; ## 4 on U31 (thru series R41 47.5 ohm)
LOC = "L15"; ## 13 on U31
LOC = "B22"; ## 5 on U31 (thru series R42 47.5 ohm)
LOC = "C22"; ## 56 on U31
LOC = "C20"; ## 57 on U31
LOC = "N22"; ## 29 on U25
LOC = "N20"; ## 25 on U25
LOC = "M22"; ## 24 on U25
LOC = "M21"; ## 23 on U25
LOC = "L19"; ## 22 on U25
LOC = "K20"; ## 21 on U25
LOC = "H22"; ## 20 on U25
LOC = "H21"; ## 19 on U25
LOC = "L17"; ## 8 on U25
LOC = "K17"; ## 7 on U25
LOC = "G22"; ## 6 on U25
LOC = "G20"; ## 5 on U25
LOC = "K18"; ## 4 on U25
LOC = "K19"; ## 3 on U25
LOC = "H20"; ## 2 on U25
LOC = "J19"; ## 1 on U25
LOC = "E22"; ## 55 on U25
LOC = "E20"; ## 18 on U25
LOC = "F22"; ## 17 on U25
LOC = "F21"; ## 16 on U25
LOC = "H19"; ## 11 on U25
LOC = "H18"; ## 10 on U25
LOC = "F20"; ## 9 on U25
LOC = "G19"; ## 26 on U25
LOC = "AA20"; ## 34 on U25, 8 on U32 (thru series R132 100 ohm), 6 on J17
LOC = "R13"; ## 36 on U25, 3 on J17
LOC = "T14"; ## 39 on U25, 2 on J17
LOC = "AA6"; ## 41 on U25
LOC = "AB6"; ## 47 on U25
LOC = "Y5"; ## 49 on U25
LOC = "AB5"; ## 51 on U25
LOC = "W9"; ## 53 on U25
LOC = "T7"; ## 35 on U25
LOC = "U6"; ## 37 on U25
LOC = "AB19"; ## 40 on U25
LOC = "AA18"; ## 42 on U25
LOC = "AB18"; ## 48 on U25
LOC = "Y13"; ## 50 on U25
LOC = "AA12"; ## 52 on U25
LOC = "AB12"; ## 54 on U25
LOC = "T18"; ## 56 on U25
