Tippmann A-5 MARKER LINE Owner's Manual page 6

Remote Coil: Connecting and Disconnecting
E
WARNING
N
NEVER INSTALL PRESSURIZED AIR TO THE MARKER WITHOUT THE
TOMBSTONE PUSH PIN
G
IS SET - HOLDING THE TOMBSTONE
L
1) ❏ Remove the air supply from the marker Remote Coil as outlined in
I
the Air Supply Cylinder Removal instructions on pages 18-20. Never
disassemble a marker or remove a remote coil that is under pressure.
S
2) ❏ Check that the Tombstone
H
Push Pin is installed.
3) ❏ Check that the Tombstone
Latch is set .
4) ❏ Check that Gas Line Adapter
and nipple fitting are secure.
5) ❏ Pull and hold the Remote Coil
fitting Locking Ring down
or remove the Remote Coil fitting
6) ❏ With the Locking Ring held
down , push the coil fitting
up onto the nipple and release
the locking ring up to lock
7) ❏ Pull down
on the
Remote Coil fitting to be sure it has locked properly.
❏ To turn off air supply: turn
❏ To turn on air supply: turn
E-GRIP OPERATING INSTRUCTIONS
READ AND FOLLOW THE E-GRIP
13) COMPLETELY BEFORE INSTALLING THE AIR SUPPLY CYLINDER AS
OUTLINED IN – GETTING STARTED - STEP 2: ON PAGE 6.
• INSTALL THE AIR SUPPLY AND LOAD THE HOPPER WITH PAINTBALLS
ONLY AFTER YOU:
❏ ❏ ❏ ❏ ❏ HAVE THE BARREL BLOCKING DEVICE INSTALLED (SEE PAGE 2);
❏ ❏ ❏ ❏ ❏ HAVE THE TRIGGER SAFETY IN SAFE MODE (SEE PAGE 4);
❏ ❏ ❏ ❏ ❏ HAVE SUCCESSFULLY INSTALLED THE BATTERY ( STEP 1: PAGE 9) AND
❏ ❏ ❏ ❏ ❏ ARE FAMILIAR WITH THE E-GRIP NORMAL OPERATION (STEP 2: PAGE 9).
• EYE PROTECTION DESIGNED FOR PAINTBALL USE MUST BE WORN
BY THE USER AND ANY PERSON WITHIN RANGE.
• READ EACH STEP COMPLETELY BEFORE PERFORMING THE STEP:
INSTALLED AND THE TOMBSTONE LATCH
IN PLACE .
to install
.
.
flow control completely out
flow control completely in
WARNING
OPERATING INSTRUCTIONS (PAGES 8-
TM
8
E-GRIP TM Operating Instructions
(continued on page 9)
E-GRIP TM Operating Instructions (continued from page 8)
STEP 1: E-GRIP Battery Installation or Replacement:
TM
To Install the battery: ❏ Remove the battery door
the back of the E-Grip by pulling up and back on the tab
TM
NOTE: When removing the battery clip
Do Not pull it off by the wires
❏ Plug a 9 volt battery into the battery clip.
❏ Insert the battery into the E-Grip
at the top and wires as shown.
❏ Reinstall the battery door - Replace the battery door with
the tab down, press the tab
it locks back into the E-Grip TM .
NOTE: The E-Grip TM Low Battery Indicator feature: the "Ready
To Fire" Flashing Green LED will turn to blinking red when
the battery is low and needs replaced (see - Low Battery
Condition on page 10).
STEP 2: Power On - Basic Operation
1) To turn the E-Grip TM power on:
❏ Use a small object like an allen wrench (
press and hold the power button
The LED will light orange then green when the
electronics have been activated.
❏ Release the power button and the green LED
begin flashing green to show the power is on and the
battery is good. (NOTE: ❏ If the LED begins flashing
red, see - Low Battery Condition on page 10).
❏ If pressing the power button failed to turn on
the LED light, see Troubleshooting section on page 13.
2) Safety/Selector operation -
The 3-position safety/selector switch
S = Safe (as shown);
F = Semi-Auto
(One pull/release
of the trigger
fires 1 time).
FA = Special Firing Mode. The Special Firing Mode can be set to any 1
of 5 firing options as detailed in the Special Firing Mode section.
3) To fire the marker - ❏ ❏ ❏ ❏ ❏ select either the F or FA position using the safety/
selector switch and pull the trigger. The LED
pull of the trigger.
4) Changing Special Firing Modes - ❏ ❏ ❏ ❏ ❏ To change the Special Firing Mode
while the E-Grip TM is powered on, press and hold the power button
1/2 second. The LED will flash orange to represent the number of the Special
from
.
from the battery,
.
TM with the battery clip
and listen for the snap as
) to
for 2 seconds.
will
has three settings:
will light orange with each
E-GRIP TM Operating Instructions
9
(continued on page 10)
E
N
G
L
I
S
H
for a
