Tippmann A-5 Parts List

A-5 TM Parts List
02-29L
02-30
Hopper
Hopper
Left Side
Lid
02-31
Hopper Screws
(7)
02-39
A-5 Barrel
PL-42D
02-40
1/4-20
Barrel
Nut
O-ring
TA01100
Receiver,
Left Black
02-13
Cocking
98-01A
Handle
Receiver
02-69
Bolt (6)
Barrel
(Short)
Adapter
02-41
Feeder
Housing
Bolt
02-24
Tombstone
Adapter
02-07
Front Grip
02-PIN
Push Pin
98-45
(4)
Flat Washer
CA-40
Front Grip
18-PA
PL-42A
Bolt
O-Ring
Screw
02-09 Gas Line
98-55
Safety
INTERNAL VALVE PARTS
O-ring
02-72 Valve O-ring Large
Red
02-71 Valve Washer
PA-32 Valve Spring
98-PL Valve Plunger
CA-27 Valve Seat
SL2-25 Valve O-ring Small
02-25 Valve Body
02-34
Hopper
Lid
Spring
02-15
Front
Sight
TA01101
Receiver
Right Black
9-PA
Receiver
FA-18
Nut
Ball
Latch
02-73
SL2-4 Front
Tombstone
Bolt O-ring
Latch
98-16
Linkage
Arm
02-17
Front
Bolt
02-14
02-70
Cocking Handle
Name Plate
Spring
02-38
Trigger
Guard
02-37
Safety
02-02L
Lower Receiver
Left
98-01B 02-10
Receiver Gas Line
Bolt Long Elbow
02-29R
DO NOT FIELD STRIP OR OTHERWISE DISASSEMBLE
Hopper
Right THIS MARKER WHILE IT IS PRESSURIZED WITH AIR.
Side
PL-42A Screw
02-48 Feeder Screw,Washer
98-20
02-46 Upper Sprocket
Rear
Sight 02-45 Lower Sprocket
Spring
02-27
02-43 Cyclone
Rear
02-52L
Sight
Ratchet
Pin (Long)
02-28
02-53 Ratchet
02-20 Sear
02-50
Spring (Blue)
Feeder
Rachet
02-22 Velocity
Spring
Screw
PL-42A
02-21
Power Screw
Tube
02-44 Feeder Bottom Plate
02-42 Feeder Housing Nut
98-12A
02-02R
Valve/Rear Bolt
Lower
O-ring (2)
Receiver
Right
02-V
Valve
Complete
02-36
02-20S
Trigger
Trigger
02-33 Trigger
Spring
9-PA
Plate Pin (5)
Red
98-19
Trigger
Slider
Pin (2)
02-06 02-67L
Tank Left
Adapter Trigger Plate
WARNING
TIPPMANN
1-800-533-4831
www.tippmann.com
RIGHT TRIGGER PLATE WITH
PARTS SHOWN IN POSITION
TM Feeder
02-20S
Housing
Spring (Red)
02-52S
Ratchet Pin
(Short)
02-20S Trigger
Spring Red
Trigger
02-51 Rachet
Slider
Spring Guide
Pins
02-49 Feeder Axle
Trigger
02-64 Cylinder Plug
02-66 Cylinder Spring
02-63 U cup Seal
SL2-6 Cylinder Reset O-ring
20-07
02-54
Banjo
Cylinder
Fitting
Piston
02-65
Feeder
Reset
Rod
02-62
Feeder
Cylinder
02-11 Rear Bolt
CA-14 Drive Spring
CA-15 Guide Pin
02-60 End Cap Snap Ring
02-33A
Sear Pin
(Black)
02-35
02-67R
Sear
02-20
Right Trigger Plate
Sear
98-18 Trigger Slider
Spring
(Blue) 98-20 Slider Spring (Yellow)
TM
02-33A Sear Pin 02-35
(Black)
Sear 02-20
Sear
Spring
Blue
Right
Trigger
02-33
Plate
Pins (5)
Slider
(Yellow Spring - not visible)
20-18 Cylinder Hose
20-07
Banjo
Fitting
02-61
Reset Button
98-57 Buffer O-ring
02-58 O-ring Retainer
02-05 End Cap
02-59
End Cap
Bushing
4-PA
Sling Swivel
REV 06/01/2005
