Intergraph InterServe 9000 System Reference Manual page 44

34
The default RAID configuration for the three standard RAID drives is as follows:
u
RAID level - 5
u
Write policy - write through
u
Device Spinup - two drives every 12 seconds
u
Ultra SCSI - enabled
If you modify the RAID configuration, and want to return to the default settings, use the
following procedure.
To reset the default RAID configuration:
1. Reboot the system.
2. When prompted, press
Menu displays.
MYLEX Disk Array Controller-Configuration Utility Version X.XX X/XX/XX
2 Channel - 7 Target DAC960P #1
If more than 3 Physical Drives are present, choose this
option to create one RAID 5 System Drive automatically.
Use cursor keys for selection, hit <ENTER> to select, <ESC> to Quit
The Help window (box below the Main Menu) briefly describes the operations you can
perform with the highlighted option. Use the cursor keys to select the options in the
Main Menu and press
3. Move the cursor down and select New Configuration to set up one 8 GB array to RAID
level 5, and "write through" write policy.
4. Restart the system.
+ to enter the Mylex RAID configuration utility. The Main
ALT R
Main Menu
01. Automatic Configuration
02. New Configuration
03. View/Update Configuration
04. Rebuild
05. Initialize System Drive
06. Consistency Check
07. Tools
08. Select DAC960
09. Advanced Functions
10. Diagnostics
to select the highlighted option.
ENTER
Firmware version x.xx
