Intergraph InterServe 9000 System Reference Manual page 19

To attach the mounting brackets to the back vertical rail:
Use the same procedure to install both mounting brackets on the back vertical rails. See
the following figure for proper orientation of the short mounting bracket.
Short Mounting
Bracket
Phillips flathead screw,
#10-32 x .5
To prepare the slide assemblies:
1. Remove the slide assemblies from the kit. See the following figure.
1
5
Back Vertical Rail
Bar Nut
4
1 Large outer bar
2 Center bar
3 Small outer bar
4 Safety latch on the small outer bar
5 Safety latch on the center bar
2 3
9
