2. Orient a center bar and large outer bar assembly so that the flat side is facing toward the
mounting brackets attached to the vertical rails, and the safety latch on the center bar is
near the back of the rack. Press the flat side of the outer bar into the mounting bracket.
3. Slide the assembly toward the front of the rack until the end of the outer bar is
approximately 90 millimeters from the leading edge of the bracket.
4. Gently slide the center bar toward the front of the rack, and position the oblong slot in it
over the first hole in the large outer bar. Insert an 8-32 screw through the hole in the
bar and the first slot in the front bracket. Place an 8-32 kep nut on the screw, and
loosely tighten it.
5. Position the oblong slot in the center bar over the third hole back from the front of the
large outer bar. Insert an 8-32 screw through the hole and the oblong slot in the front
bracket. Place an 8-32 kep nut on the screw and loosely tighten it.
6. The back mounting bracket has one slot in it. The end of the outer bar has four holes in
it. The holes you use depend on the depth of the equipment rack. After fitting the bar
into the mounting bracket, insert two screws through the appropriate holes in the bar
and the slot in the mounting bracket. Place an 8-32 kep nut on each screw, and loosely
tighten them.
7. Ensure that the mounting brackets and bars are positioned correctly in the rack. Then
tighten all screws firmly (6.0 inch-pounds).

Prepare the System

Before installing the base unit in the 19-inch equipment rack, you must attach the small bars
of the slide assemblies onto the sides of the system. You must also attach two chassis
handles to the system faceplate.
To attach the small bar of the slide assembly to the system:
1. Remove four #8-32 x .5 Phillips trusshead screws from the parts box. See the figure
below for the small bar of the slide assembly.
2. While facing the side of the system, orient the small bar so that the flat side faces the top
and the right-angle end faces the front of the system.
3. Align the first hole in the right-angle end of the bar with the first threaded hole in the
side of the chassis.
4. Insert a screw through the hole in the bar and into the chassis. Then loosely tighten the
screw.
11
