Hspa Modem Interface - EUROCOM Notebook V09.1.00BETA User Manual

Modules & Options
HSPA Modem Help
To get help on HSPA
modem configuration
and settings, click the
help icon and select
Help.
7
Figure 7 - 48
HSPA Modem
Interface Window
7 - 56 3.75G/HSPA Module

HSPA Modem Interface

The connection information is stored on the USIM card supplied by the service pro-
vider.
1. Power on the 3.75G/HSPA modem module using the Fn +
2. Access the HSPA Modem interface from the Start menu (Start > Programs/All
Programs > HSPA Modem > HSPA Modem), or by double-clicking the desktop
icon .
3. If a USIM card is not installed then a message will appear to notify you of this (click
OK to close the message and install the USIM card).
4. If you are required to enter a pin # then a message will appear to prompt you to
enter a pin #. (Note: to change pin # go to Settings
code.)
5. Click the Network connection
window will display Connection Manager.
Connection Manager
The connection information is commonly stored on the USIM
card supplied by the service provider. However if your ser-
vice provider requires details such as IP Address, User-
name and Password etc. to be entered before connection
you can enter them in the Connection Manager tab, or
save the details in Profiles.
key combination.
and click OK in PIN
button and the HSPA Modem interface
