System Map: Bottom View

CPU
The CPU is not a user
serviceable part. Open-
ing this compartment, or
accessing the CPU in
any way, may violate
your warranty.
Overheating
To prevent your comput-
er from overheating
make sure nothing
blocks the Vent/Fan In-
take while the computer
is in use.
4
2
5
Battery Information
Always completely discharge, then fully charge, a new bat-
tery before using it. Completely discharge and charge the
battery at least once every 30 days or after about 20 partial
discharges. See "Battery Information" on page 3 - 10
full instructions.
1
1.
2.
3
3.
4.
4
5.
for
System Map: Bottom View 1 - 15
Quick Start Guide
Figure 1 - 8
Bottom View
Battery
Hard Disk Bay
Cover
(3.75G Module
Location)
RAM & CPU Bay
Cover
Vent/Fan Intake/
Outlet
Drainage Outlet
(see "What to do if
you Spill Liquid
on the Computer"
on page 6 - 11)
