Upgrading the Optical (CD/DVD) Device

1. Turn off the computer, and turn it over and remove the battery.
2. Locate the RAM & CPU bay cover and remove screws
3. Carefully (a fan and cable are attached to the under side of the cover) lift up
the bay cover.
4. Carefully disconnect the fan cable
2
1
4
3
-
1
, and remove the cover
5
Fan Cable
Make sure you reconnect the fan cable
5 before screwing down the bay cover.
Upgrading the Optical (CD/DVD) Device 6 - 7
Upgrading The Computer
.
4
.
6
5
6
Figure 6 - 6
Removing the RAM
& CPU Bay Cover
