EUROCOM Notebook V09.1.00BETA User Manual page 100

Upgrading The Computer
6
Figure 6 - 7
Removing the
Optical Device
6 - 8 Upgrading the Optical (CD/DVD) Device
5. Remove screws -
7
device at point .
10
6. Insert the new device and replace the optical device screws
7. Reconnect the fan cable before replacing the bay cover (
page 6 - 7).
8. Replace the bay cover and screws.
7
8
9
and use a screwdriver to carefully slide out the optical
9
10
- .
7 9
in Figure 6 - 6 on
5
