Figure 1 - 7
Rear View
1. Vent/Fan Intake/
Outlet
2. Security Lock
Slot (Model A
Only)
3. HDMI-Out Port
4. DC-In Jack
5. 2 * USB Ports
6. RJ-45 LAN Jack
7. Rear Cover
(Model B Only)
Overheating
To prevent your comput-
er from overheating
make sure nothing
blocks the vent(s)/fan in-
take(s) while the com-
puter is in use.

1 - 16 System Map: Rear View

System Map: Rear View
1
1
Note that the HDMI-Out Port supports video and audio signals to attached external dis-
plays (also see "HDMI Audio Configuration" on page B -
Model A
2 6
3
5
4
Model B
3 5
5
4
7
HDMI-Out Port
11).
