Specifications

Communication

Built-In 56K Fax Modem V.90 & V.92
Compliant
Built-In 10/100/1000Mb Base-TX Ethernet LAN
Intel® WiFi Link Wireless LAN Module 5300
3*3 802.11 a/g/n Half Mini-Card with PCIe
Interface (Factory Option)
3rd Party 802.11b/g/n Half Mini-Card
Wireless LAN Module with PCIe Interface
(Factory Option)
Bluetooth 2.1 + EDR (Enhanced Data
Rate) Module with USB Interface
(Factory Option)
2.0M Pixel USB PC Camera Module with
USB Interface (Factory Option)

Communication (cont'd)

For Model A Computers Only:
UMTS/HSPDA-based 3.75G Module with
USB Mini-Card Interface (Factory Option)
Quad-band GSM/GPRS (850 MHz, 900
C MHz, 1800 MHz, 1900 MHz)
UMTS WCDMA FDD (2100 MHz)
Note that UMTS modes CAN NOT be
used in North America.
C - 4 Specifications

Power Management

Supports Wake on LAN
Supports Wake on USB
Supports Resume From Modem Ring
Power
Full Range AC/DC Adapter
AC input 100 - 240V, 50 - 60Hz,
DC Output 20V, 6.0A OR 18.5V, 6.5A
Removable Polymer Smart Lithium-Ion
Battery Pack, 42.18WH

Security

Security (Kensington® Type) Lock Slot
BIOS Password
Fingerprint Reader Module (Factory
Option)

Operating System

Windows® Vista (with Service Pack 2)
Windows® 7

Environmental Spec

Temperature
°
Operating: 5 C - 35
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions & Weight
Model A Computers:
374mm (w) * 263.5mm (d) * 42mm (h)
3.3kg +/- 0.1kg With ODD & Battery
Model B Computers:
412mm (w) * 279mm (d) * 39-48mm (h)
4kg With ODD & Battery

Factory Options As Per Model

For Model A Computers Only:
UMTS/HSPDA-based 3.75G Module with
USB Mini-Card Interface
For Model B Computers Only:
Hybrid TV Tuner Card with USB Interface
°
C
