6 - 8 Upgrading the Optical (CD/DVD) Device

Upgrading the Optical (CD/DVD) Device
1. Turn off the computer, and turn it over and remove the battery.
2. Locate the component bay cover and remove screws
(Model B).
11
3. Carefully remove the cover
