RAID Level
Identical drives reading and writing data in parallel to increase performance. RAID 0
RAID 0 implements a striped disk array and the data is broken into blocks and each block is
written to a separate disk drive.
Identical drives in a mirrored configuration used to protect data. Should a drive that is
part of a mirrored array fail, the mirrored drive (which contains identical data) will
RAID 1
handle all the data. When a new replacement drive is installed, data to the new drive is
rebuilt from the mirrored drive to restore fault tolerance.
Prepare the following before setting up your serial ATA hard disks in RAID mode
(to configure AHCI mode you do not need to prepare any extra hard disks but will
need to install the Intel Matrix driver):
1. The Microsoft Windows OS CD.
2. A second (identical) hard disk installed in the secondary HDD bay for RAID level
0 or 1 (required for RAID but not required for AHCI).
3. The Device Drivers & Utilities + User's Manual disc.
Description
Setting Up SATA RAID or AHCI Modes 7 - 61
Modules & Options
Table 7 - 1
RAID Levels
Array Types
A Mirrored Array
(RAID 1) provides full
data protection, as
data can simply be
copied from a healthy
disk to a replacement
for any failed disk.
A Striped Array
(RAID 0) is NOT fault-
tolerant. The failure of
one drive will result in
the loss of all data in
the array. It is de-
signed to increase disk
performance by
spreading the I/O load
across the channels
and drives.
