4. Lift the hard disk assembly out of the computer in the direction of arrow
5. Remove the screws
6. Reverse the process to install a new hard disk drive (do not forget to replace all the
.
screws and covers)
4
The hard disks and covers pictured here may appear slightly different from your model design (these
designs are subject to change and upgrade without notice). Pay careful attention to the screws and
cover bracket orientation.
- and the cover bracket
5 8
5
Hard Disk Screws & Cover

Upgrading The Computer

.
4
.
9
6
7
9
8
Upgrading the Hard Disk Drive(s) 6 - 5
Figure 6 - 3
HDD Assembly
Removal
6
