System Map: Front View - Model A

2
4 5
7
9
1
The use of any portable electronic trans-
mission devices aboard aircraft is usually
prohibited. Make sure the module(s) are
OFF if you are using the computer aboard
aircraft.
Use the key combinations to toggle power
3
to the 3.75G/HSPA/WLAN/Bluetooth
6 4
modules, and check the LED indicator
icon to see if the modules are powered on
or not (see
Table 1 - 4, on page 1 -
8
10
Wireless Device
Operation Aboard Aircraft
Table 1 - 6, on page 1 -
9).
Touchpad Buttons
(valid operation area)
System Map: Front View - Model A 1 - 7
Quick Start Guide
Figure 1 - 2
Front View
(Model A Computers)
1. Built-In PC Camera
(Optional)
2. LCD
3. Power Button
4. Speakers
5. LED Hot Key
Buttons
6. LED Status
Indicators
7. Keyboard
8. Built-In Microphone
12/
9. Touchpad &
Buttons
10. LED Power
Indicators
Note: The Fingerprint
Reader module is optional
for Model A computers.
