EUROCOM Notebook V09.1.00 User Manual page 150

Modules & Options
Figure 7 - 33
Unlock the
SIMLOCK
7
Figure 7 - 34
SIMLOCK Lock
7 - 42 3.75G/HSPA Module
5. Slide the SIMLOCK towards the hinge (in the direction of the arrow illustrated in
Figure 7 - 33) in order to release the lock and lift it up.
6. Insert the USIM card as illustrated in
7. Lock the SIMLOCK by pushing it in the direction of the arrow in
it clicks into the lock position.
8. Replace the cover, screw and battery.
(Figure 7 - 34) and close the SIMLOCK.
Model A
A
Figure 7 - 34 until
