Quick Start Guide
1

System Map: Rear View

1
1. Vent/Fan Intake/Outlet
2. S/PDIF-Out Jack
3. Line-In Jack
4. 2 * USB 2.0 Ports
5. DVI-Out Port
6. CATV Jack (Enabled With TV Tuner Only)
7. RJ-11 Phone Jack
8. RJ-45 LAN Jack
9. S-Video-Out Jack
10. DC-In Jack
11. Serial Port
1 - 14 System Map: Rear View
Rear View - Model A
2 3
4
Rear View - Model B
1
2 3
4
Figure 1 - 6 - Rear View
5
7 8
6 9
5
7 8
6
To prevent your computer from overheating make
sure nothing blocks the Vent/Fan Intake/Outlet
while the computer is in use.
10 11
9 10
11
Overheating
