System Map: Rear View - EUROCOM D400K PYTHON User Manual

Concise User's Guide

System Map: Rear View

Figure 7
Rear View
1. Vent
2. DC-In Jack
3. External Monitor (VGA) Port
4. Parallel Port
5. Serial Port
6. S-Video Out Port
7. PS/2 Type Port
8. RJ-11 Phone Jack
9. RJ-45 LAN Jack
16 - System Map: Rear View
1
2
Overheating
To prevent your com-
puter from overheating
make sure nothing
blocks the vent(s)/fan
intake(s) while the com-
puter is in use.
1
3 4 5
Model A
Model B
2 3 4
6 7 8 9
5 6 7 8 9
