EUROCOM Notebook V09.1.00 User Manual page 172

Modules & Options
Figure 7 - 53
RAID Created
7
7 - 64 Setting Up SATA RAID or AHCI Modes
10. This will now return to the main menu.
Intel(R) Rapid Storage Technology - Option ROM - 9.5.0.1021
Copyright (C) 2003-09 Intel Corporation. All Rights Reserved.
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
RAID Volumes:
ID Name
0 MyRAID
Physical Disks:
Port Drive Model
0 FUJITSU MHY2120B K404T812PPG5
4 FUJITSU MHY2120B K404T7C2KJKJ
[ ]-Select
11. Select 6.Exit and press Enter, then press Y to exit the RAID configuration menu.
12. As the computer starts up, press a key when you see the message "Press any
key to boot from CD".
13. Press Enter to continue installing the operating system as normal (see your
Windows documentation if you need help on installing the Windows OS).
14. Install the Windows drivers from the Device Drivers & Utilities + User's Manual
disc as per Table 4 - 1, on page 4 -
15. After installing all the necessary system drivers you need to install the Intel Matrix
driver (see "Intel Matrix Driver Installation" on page 7 -
[ MAIN MENU ]
4. Recovery Volume Options
5. Acceleration Options
6. Exit
[ DISK/VOLUME INFORMATION ]
Level Strip Size
RAID1(Mirror) N/A 111.8GB
Serial # Size
111.7GB
111.7GB
[ESC]-Exit [ENTER]-Select Menu
3.
Status Bootable
Normal Yes
Type/Status(Vol ID)
Member Disk(0)
Member Disk(0)
65).
