LED Indicators

The LED indicators on the LED strip just below the
LCD panel on the computer display helpful informa-
tion about the current status of the computer when il-
luminated.
Icon
Hard Disk Activity
Number Lock Activated
(to activate press Fn & Num Lk)
Caps Lock Activated
Scroll Lock Activated
(to activate press Fn & Scr Lk)
The (optional) Wireless LAN Module is Powered
The (optional) Bluetooth Module is Powered On
Table 1 - 3 - LED Status Indicators
Description
On
A further two LED power indicators on the front right
of the computer provide information on the comput-
er's power status.
Icon Color
Orange
Green
Blinking Green
Orange
Green
Blinking Orange
Table 1 - 4 - LED Power Indicators
Quick Start Guide
Description
DC Power is Plugged In
The Computer is On
The Computer is in Sleep
Mode
The Battery is Charging
The Battery is Fully Charged
The Battery Has Reached
Critically Low Power Status
LED Indicators 1 - 9
