RAID Setup (Intel Matrix)

1. Press Ctrl + i to enter RAID configuration menu.
Copyright (C) 2003-09 Intel Corporation. All Rights Reserved.
1.
2.
3.
RAID Volumes:
None Defined
Physical Disks:
Port Drive Model
0 FUJITSU MHY2120B K404T812P22B
1 FUJITSU MHY2120B K404T7C2KJ14
[ ]-Select
2. Select 1.Create RAID Volume and press Enter.
3. Type the RAID volume name and then press Tab or Enter to advance to the next
field.
4. Specify (use the up and down arrow keys) the RAID level (RAID 0 or RAID 1 see
Table 7 - 1, on page 7 -
field.
5. Press Enter and the system will select the physical disks to use.
6. Press Enter and select (if applicable) the Strip Size (best set to default).
7. Press Enter and select the Capacity size (best set to default).
8. Press Enter to select Create Volume.
9. Press Enter to create the volume, and confirm the selection by pressing Y.
Intel(R) Rapid Storage Technology - Option ROM - 9.5.0.1021
[ MAIN MENU ]
Create RAID Volume 3. Recovery Volume Options
Delete RAID Volume 4. Acceleration Options
Reset Disks to Non-RAID 6. Exit
[ DISK/VOLUME INFORMATION ]
Serial # Size
111.7GB
111.7GB
[ESC]-Exit [ENTER]-Select Menu
61) and then press Tab or Enter to advance to the next
Type/Status(Vol ID)
Non-RAID Disk
Non-RAID Disk
Setting Up SATA RAID or AHCI Modes 7 - 63
Modules & Options
Figure 7 - 52
Intel(R) Matrix
Storage Manager
Option ROM
