RAID Setup (Intel Matrix)

1. Press Ctrl + i to enter RAID configuration menu.
Intel(R) Matrix Storage Manager option ROM v6.1.0.1002 ICH8R wRAID5
Copyright (C) 2003-06 Intel Corporation. All Rights Reserved.
RAID Volumes:
None Defined
Physical Disks:
Port Drive Model
0 FUJITSU MHV2040B NW56T5C25FAF
1 FUJITSU MHT2060B NR0UT52256W7
[ ]-Select
2. Select 1.Create RAID Volume and press Enter.
3. Type the RAID volume name and then press Tab or Enter to advance to the next
field.
4. Specify (use the up and down arrow keys) the RAID level (RAID 0 or RAID 1 or
RAID 5 - see Table 7 - 1, on page 7 -
the next field.
5. Press Enter and the system will select the physical disks to use.
6. Press Enter and select (if applicable) the Strip Size (best set to default).
7. Press Enter and select the Capacity size (best set to default).
8. Press Enter to select Create Volume.
9. Press Enter to create the volume, and confirm the selection by pressing Y.
[ MAIN MENU ]
1. Create RAID Volume
2. Delete RAID Volume
3. Reset Disks to Non-RAID
4. Exit
[ DISK/VOLUME INFORMATION ]
Serial # Size Type/Status(Vol ID)
93.2GB Non-RAID Disk
55.9GB Non-RAID Disk
[ESC]-Exit [ENTER]-Select Menu
3) and then press Tab or Enter to advance to
Setting Up SATA RAID or AHCI Modes 7 - 5
Modules
Figure 7 - 1
Intel(R) Matrix
Storage Manager
