System Map: Top View with LCD Panel Open

The following pages are a general map of the system's features. Detailed descriptions of the functions, setup and sys-
tem controls are covered in the expanded User's Manual.
1
2
3
5
9
10
11
Model A
7
4
11
6
8
11 11
1
3
2
4
5 6
8
9
10
11
Model B
System Map: Top View with LCD Panel Open - 9
Concise User's Guide
Figure 1
Top View with
LCD Panel Open
1. Optional PC
Camera
2. LCD Panel
3. Built-In Microphone
4. LED Power &
7
Communication
Indicators
5. LED Status
Indicators
11
6. Hot-Key Buttons
7. Close Cover
Switch
8. Power Button
9. Keyboard
11
10. TouchPad and
Buttons
11. Built-In Speakers
