System Map: Top View with LCD Panel Open

Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission de-
vices aboard aircraft is usu-
ally prohibited. Make sure
the module(s) are OFF if
you are using the computer
aboard aircraft.
Use the key combination/
switch to toggle power to
the WLAN/Bluetooth mod-
ules, and check the status
indicator icon to see if the
module is powered on or
not (see Table 1 - 1, on
page 1 - 6/Table 1 - 2, on
page 1 - 7/Table 1 - 3, on
page 1 - 8).
1
2
5
6
8
9
Figure 1 - 2 - Top View with LCD Panel Open
System Map: Top View with LCD Panel Open 1 - 5
1. LCD
2. WLAN Power Switch
3. TouchPad Power Button
4. Power Button
5. Keyboard
6. TouchPad and Buttons
7. Fingerprint Reader
8. LED Indicators
9. LCD Latch
4
Security Modules
3
The encrypted channel between
the Trusted Platform Module
security chip and the fingerprint
reader with Protector Suite
Software provides a high level of
security for your computer. See
"Security Modules (Fingerprint
7
& TPM)" on page 7 -
Quick Start Guide
6.
