Interface (Ports & Jacks)

Ports and Jacks

Item

Card Reader

Cable (CATV)

Antenna Jack

Consumer Infrared
Transceiver
A

DC-In Jack

DVI-Out Port

A - 2 Interface (Ports & Jacks)
The card reader allows you to use the following digital storage cards:
SD (Secure Digital) / Mini SD / SDHC / SDXC
Push the card into the slot and it will appear as a removable device.
Use this jack to connect a CATV cable if you have included the optional Mini-PCI TV Tuner in
your purchase.
The consumer infrared transceiver at the front of the computer allows the computer to
communicate with the remote control unit supplied with the optional Mini-PCI TV Tuner.
Plug the supplied AC/DC adapter into this jack to power your computer.
The DVI-Out (Digital Visual Interface) Port is a video connector interface. This allows you to
connect an external monitor, TV or Flat Panel Display etc. as a display device (see
an External Display using the NVIDIA Control Panel" on page B -
If you are using an older type of monitor you will need to use a converter to convert the signal
from DVI to VGA.
Description
MMC (MultiMedia Card) / RSMMC
MS (Memory Stick) / MS Pro / MS Duo
"Configuring
7) by means of a DVI cable.
