Upgrading The Computer
Figure 6 - 3
Hard Disk Assembly
Screws & Removal
6
6 - 6 Upgrading the Hard Disk Drive(s)
4. Disconnect the HDD cable
5. Remove screws -
5
6. Pull the tab to disconnect the hard disk assembly from the connector.
9
7. Remove the hard disk assembly
8. Remove the HDD board & cable
4
5
7
11
.
4
from the hard disk assembly.
