EUROCOM Notebook V11.6.00 User Manual page 127

Removing the Hard Disk from the Secondary HDD Bay
1. Remove the battery (the Secondary hard disk bay is located under the battery).
2. Remove screws -
1
3. Grip the tab and slide the hard disk assembly in the direction of the arrow
4. Lift the hard disk assembly out of the compartment.
from the hard disk assembly.
4
1 2
3 4
5
Upgrading The Computer
.
5
Upgrading the Hard Disk Drive(s) 6 - 11
Figure 6 - 8
Secondary HDD
Assembly Removal
6
