Upgrading The Computer
Figure 6 - 14
Keyboard Screws
6
Figure 6 - 15
Disconnect the
Keyboard Locking
Collar
6 - 16 Upgrading the System Memory (RAM)
5. Remove screws -
6
6
6. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable.
7. Disconnect the keyboard ribbon cable
from the keyboard.
10
7 8
from the locking collar socket
11
9 10
.
12
11
12
