Upgrading The Computer
Figure 6 - 21
6
Keyboard Shielding
Plate Insertion
6 - 20 Upgrading the System Memory (RAM)
Keyboard Shielding Plate Insertion
1. When re-inserting the keyboard shielding plate
ing it into position at an angle as illustrated by arrow
into position.
2. Secure the plate with screws
3
1
- .
3 5
1
2
4
5
make sure you insert it by slid-
below, and press it down
2
