EUROCOM Notebook V09.2.00 User Manual page 100

Upgrading The Computer
RAID Hard Disks
All hard disks in a RAID
should be identical (the
same size and brand) in
order to prevent unex-
pected system behavior.
6
Figure 6 - 4
Secondary HDD
Removal
6 - 6 Upgrading the Hard Disk Drive(s)
Removing the Hard Disk(s) in the Secondary HDD Bay
1. Turn off the computer, and turn it over and remove the battery.
2. The secondary hard disk bay is located under the battery compartment.
3. Remove screw .
21
4. Slide the hard disk assembly in the direction of the arrow
5. Lift the hard disk assembly
6. Remove the screws
24
22
27
26
out of the compartment.
23
- to release the hard disk from the case.
27
21
24
25
.
22
23
