Interface (Ports & Jacks)

Ports and Jacks

Item

Card Reader

Cable (CATV)

Antenna Jack

Consumer Infrared
Transceiver

DC-In Jack

A

DVI-Out Port

e-SATA Port

e-SATA
A - 2 Interface (Ports & Jacks)
The card reader allows you to use the following digital storage cards:
MMC (MultiMedia Card)
SD (Secure Digital)
MS (Memory Stick)
MS (Memory Stick Pro)
Use this jack to connect a CATV cable if you have included the optional TV Tuner in your
purchase.
The consumer infrared transceiver at the front of the computer allows the computer to
communicate with the remote control unit supplied with the optional TV Tuner.
Plug the supplied AC/DC adapter into this jack to power your computer.
The DVI-Out (Digital Visual Interface) Port (at the rear of the computer) allows you to connect an
external monitor, or Flat Panel Display, to allow dual video or simultaneous display on the LCD
and external monitor/FPD (see
of monitor you will need to use a converter to convert the signal from DVI to VGA.
Plug external Serial ATA hard drives into this e-SATA (external Serial Advanced Technology
Attachment) port. Install the Intel Matrix Storage driver to display the safe removal icon for e-
SATA devices in the taskbar (see
Description
RS MMC (requires PC adapter)
Mini SD (requires PC adapter)
MS Duo (requires PC adapter)
"Display Devices" on page B -
"Intel® Matrix Driver Installation" on page 7 -
5). If you are using an older type
42).
