System Map: Right & Bottom Views
3
3
4
1
1
6
3
3
5
2
Battery Information
Always completely dis-
charge, then fully charge, a
new battery before using it.
Completely discharge and
charge the battery at least
once every 30 days or after
about 20 partial discharges.
See "Battery Information"
on page 3 - 10 for full in-
structions.
System Map: Right & Bottom Views 1 - 15
Quick Start Guide
Figure 1 - 8
Right & Bottom
Views
1. USB Ports
2. Security Lock
Slot
3. Fan Outlet/Intake
4. Battery
(Secondary HDD
Bay - HDD3)
5. Primary HDD
Bay (HDD1 & 2)
6. Component Bay
Cover
Overheating
To prevent your comput-
er from overheating
make sure nothing
blocks the vent(s)/fan in-
take(s) while the com-
puter is in use.
1
