EUROCOM Notebook V09.2.00 User Manual page 99

-
4. Remove screws
6
connector .
10
5. Lift the hard disk assembly out of the computer.
6. Remove screws -
11
7. Separate the hard disk(s) from the bracket
8. Insert the new hard disk(s) into the computer.
9. Re-Insert the bracket and insert screws.
7
6
8
and pull the tab to release the cable
8
(if two hard disks are installed).
18
and connector cable
19
10
12
11
9
Upgrading The Computer
from the
9
.
20
13
14
15
19
16
17
18
20
Upgrading the Hard Disk Drive(s) 6 - 5
HDD System Warning
New HDD's are blank. Be-
fore you begin make sure:
You have backed up any
data you want to keep from
your old HDD.
You have all the discs re-
quired to install your oper-
ating system and
programs.
If you have access to the in-
ternet, download the latest
application and hardware
driver updates for the oper-
ating system you plan to in-
stall. Copy these to a
removable medium.
Figure 6 - 3
Primary HDD
Removal
6
