Setting Up SATA RAID or AHCI Modes

AHCI Mode

Advanced Host Controller Interface (AHCI) is an interface specification that allows
the storage driver to enable advanced serial ATA features such as Native Command
Queuing (for maximum hard disk efficiency and performance). AHCI mode can be
supported by one, two or three hard disks.

RAID

You may use your identical (see sidebar) hard disks (if you have included more than
one hard disk in your purchase option) in combination with Striping (RAID 0), Mir-
roring (RAID 1) or Intel® Rapid Recover Technology (Recovery) for fault tolerance
and data recovery (see Table 7 - 1, on page 7 -
Striping (RAID 0) or Mirroring (RAID 1) modes you will require at least two hard
disks; to configure your system in Intel® Rapid Recover Technology (Recovery)
mode you will require two hard disks only installed.
Intel Matrix Storage Manager
®
Make sure you install the Intel Matrix driver and application if you have set up your
hard disk(s) in AHCI or RAID modes (see
page 7 - 42).
36). To configure your system in
"Intel® Matrix Driver Installation" on
Setting Up SATA RAID or AHCI Modes 7 - 35
Modules
RAID Hard Disks
All hard disks in a RAID
should be identical (the
same size and brand) in
order to prevent unex-
pected system behavior.
7
