EUROCOM Notebook V09.2.00 User Manual page 110

Upgrading The Computer
Figure 6 - 15
Video Card Fan
Screws
6
Figure 6 - 16
Heat Sink Screws
6 - 16 Upgrading the Video Card
4. Remove screws -
12
5. Remove screws -
16
from the video card fan and disconnect the fan cable
14
15
12
13
from the heatsink in the order indicated on the label.
19
17 19
18 16
14
.
15
