6. Fully loosen screws
17
7. Disconnect cable .
24
8. Carefully (make sure all the screws are sufficiently loosened and cables
disconnected) remove the heat sink and fan unit
- in the order indicated here (and on the label).
23
25
20
19
17
18
24
21
25
Upgrading The Computer
.
22
23
Upgrading the System Memory (RAM) 6 - 9
Figure 6 - 7
Heat Sink
Removal
Caution
The heat sink, and
CPU area in general,
contains parts which
are subject to high
temperatures. Allow
the area time to cool
before removing these
parts.
6
