Quick Start Guide
1
1. LCD Latches
2. Line-In Jack
3. S/PDIF-Out Jack
4. Microphone-In
Jack
5. Headphone-Out
Jack
6. Speakers
7. Vent/Fan Intake
8. DC-In Jack
9. DVI-Out Port
10. S-Video-In Jack
*
Enabled with Optional
Mini-PCI TV Tuner Only
1 - 10 System Map: Front & Rear Views
System Map: Front & Rear Views
1
6
7
*
To prevent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s)
while the computer is in use.
2 3 4 5
8 9
Overheating
Figure 1 - 4 - Front & Rear Views
1
6
7
10
