System Map: Right & Bottom Views
To prevent your computer from overheating make sure nothing blocks the vent(s)/fan in-
take(s) while the computer is in use.
Figure 1 - 6 - Right & Bottom Views
1 1
6
4
4
4
3 5
Overheating
2
4
System Map: Right & Bottom Views 1 - 13
Quick Start Guide
1. USB Ports
2. Security Lock
Slot
3. Battery
(Secondary HDD
Bay - HDD3)
4. Fan Outlet/Intake
5. Primary HDD
Bay (HDD1 &
HDD2)
6. Component Bay
Cover
Battery Information
Always completely discharge,
then fully charge, a new battery
before using it. Completely dis-
charge and charge the battery
at least once every 30 days or
after about 20 partial discharg-
"Battery Informa-
es. See
tion" on page 3 - 10
for
full instructions.
