Interface (Ports & Jacks)
Item Description

Headphone-Out Jack

Headphones or speakers may be connected through this jack. Note: Set your system's volume
to a reduced level before connecting to this jack.

Line-In Jack

The Line-In jack allows you to play audio sources through the computer's speakers. Note that
audio input through Line-in will default to the mute setting. To set up your audio sources to play
through the Line-in jack go to the Sound control panel and make sure the Mute box is not
ticked.

Microphone-In Jack

Plug an external microphone in to this jack to record on your computer.

Mini-IEEE 1394 Port

This allows high-speed connection to various peripheral devices, e.g. external disk drives and
digital cameras (see note below).
A
IEEE 1394
The Mini-IEEE 1394 ports only support SELF POWERED IEEE 1394 devices.

RJ-11 Phone Jack

This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11
telephone connection.
Interface (Ports & Jacks) A - 3
